Rated frequency 50 Hz High Voltage Disconnecting Switch Featuring Protection Degree IP4X Designed for Power System Disconnection

Product Description:

The Medium Voltage Switchgear is an essential component in modern electrical distribution systems, designed to ensure the reliable and safe management of electrical power in medium voltage networks. Engineered to meet the rigorous demands of industrial, commercial, and utility applications, this switchgear provides robust performance and exceptional durability, making it an indispensable solution for controlling and protecting electrical circuits.

One of the key features of this Medium Voltage Switchgear is its rated operating voltage of AC220 Ua, which allows it to handle medium voltage levels efficiently. Operating at a rated frequency of 50 Hz, this switchgear is perfectly suited for use in regions and applications where this standard frequency is prevalent. The switchgear is also designed to withstand a rated short circuit duration of 4 seconds, ensuring it can manage fault conditions with resilience and maintain system stability during electrical disturbances.

Compliance with the IEC62271 standard underscores the switchgear’s adherence to international safety and performance benchmarks. This standard is vital for guaranteeing that the equipment meets all necessary criteria related to design, testing, and operational capabilities. By aligning with IEC62271, the Medium Voltage Switchgear assures users of its reliability and conformity to globally recognized electrical safety protocols.

Protection is a critical aspect of any switchgear, and this product excels with a protection degree of IP4X. This rating indicates that the switchgear is effectively safeguarded against the ingress of solid objects larger than 1 millimeter, such as wires or small tools, thereby enhancing the operational safety and longevity of the equipment in various environmental conditions.

Incorporating advanced technology, the Medium Voltage Switchgear integrates features akin to a High Voltage Disconnect Switch, facilitating the safe isolation of electrical circuits for maintenance or emergency purposes. This capability is crucial in ensuring the safety of personnel and equipment by preventing accidental energization during service activities. The inclusion of this function within the switchgear highlights its versatility and critical role in power system management.

Moreover, the switchgear design often includes elements similar to an Electronic Dimmer Switch, which allows for precise control over voltage levels and power flow within the electrical network. This feature supports energy efficiency and enhances the overall control scheme by enabling smooth adjustment of electrical parameters, contributing to optimized system performance and reduced energy consumption.

The Medium Voltage Switchgear’s robust construction and intelligent design make it an ideal choice for a variety of applications, from industrial plants and commercial buildings to utility substations. Its ability to function reliably under medium voltage conditions while providing high levels of protection and operational control ensures that it meets the complex demands of modern electrical distribution systems.

In summary, the Medium Voltage Switchgear is a high-performance, reliable, and safe solution engineered to handle medium voltage electrical distribution with ease. Its rated frequency of 50 Hz, rated operating voltage of AC220 Ua, and 4-second rated short circuit duration provide a strong foundation for dependable operation. Adherence to the IEC62271 standard and a protection degree of IP4X further enhance its suitability for diverse environments and applications. Incorporating functionalities similar to a High Voltage Disconnect Switch and an Electronic Dimmer Switch, this switchgear offers comprehensive control and protection capabilities, making it an essential component in any electrical power management system.

Features:

• Product Name: Medium Voltage Switchgear
• Type: Box Type Gas Insulation Metal-clad Switchgear
• Rated Voltage: 12 KV
• Rated Frequency: 50 Hz
• Rated Short-Time Withstand Current: 20 KA
• Rated Power Frequency Withstand Voltage: 42/48 KV
• Equipped with High Voltage Disconnect Switch for enhanced safety
• Includes Electronic Dimmer Switch for precise control
• Features High Voltage Disconnecting Switch to ensure reliable operation

Technical Parameters:

Applications:

The TIANAN HXGT6-12 Medium Voltage Switchgear, also known as the Box Type Gas Insulation Metal-clad Switchgear, is a highly reliable and efficient solution designed for various electrical distribution and control applications. Manufactured in China and certified under IEC & GB standards, this product meets stringent international quality and safety requirements. With a rated current of 630 A and a rated peak withstand current of 50 KA, it ensures robust performance in medium voltage networks.

This switchgear is ideally suited for use in power plants, substations, industrial facilities, and commercial buildings where stable and secure power distribution is critical. Its IP4X protection degree guarantees safety against solid foreign objects, enhancing operational reliability in demanding environments. The HXGT6-12 model complies with IEC62271 standards, further ensuring its suitability for medium voltage electrical systems.

The TIANAN Medium Voltage Switchgear incorporates advanced features such as the Electronic Dimmer Switch and High Voltage Disconnecting Switch, enabling precise control and safe disconnection of electrical circuits. The inclusion of a High Voltage Disconnect Switch ensures maintenance and emergency operations can be conducted safely without disrupting the entire power system. This makes it an excellent choice for applications requiring frequent switching and reliable isolation of electrical equipment.

Thanks to its gas-insulated and metal-clad design, this switchgear occupies minimal space while providing enhanced safety against electrical faults. It is packaged securely in a wooden case for safe transportation and is available with flexible payment terms including FOB, EXW, and CIF. With a supply capacity of 500 sets per year and a delivery time of 30 days per set, TIANAN ensures timely availability for projects of various scales.

Whether used in urban power distribution networks, industrial automation systems, or energy infrastructure projects, the HXGT6-12 switchgear from TIANAN offers a dependable and cost-effective solution. Its minimum order quantity of one set makes it accessible for both large-scale and smaller projects, with pricing details available upon request. Overall, this medium voltage switchgear effectively combines safety, durability, and advanced functionality to meet the diverse needs of modern electrical applications.

Customization:

TIANAN offers the HXGT6-12 Medium Voltage Switchgear, designed and manufactured in CHINA with IEC&GB certification, ensuring compliance with international quality standards. This High Voltage Disconnecting Switch features a rated peak withstand current of 50 KA and operates at a rated frequency of 50 Hz, providing reliable performance under demanding conditions.

With a rated operating voltage of AC220 Ua and a rated short circuit duration of 4 seconds, this High Voltage Disconnect Switch is built to handle critical electrical distribution needs. The product adheres to the IEC62271 standard, guaranteeing safety and efficiency in medium voltage applications.

The HXGT6-12 model is available with a minimum order quantity of 1 SET, with pricing to be confirmed. Each unit is securely packaged in a WOODEN CASE to ensure safe delivery. Delivery time is approximately 30 days per set, supported by flexible payment terms including FOB, EXW, CIF, and more.

TIANAN’s supply ability for this High Voltage Disconnect Switch reaches 500 units per year, making it a dependable choice for large-scale projects. Trust in the quality and performance of TIANAN’s Medium Voltage Switchgear for your electrical distribution and switching needs.

Support and Services:

Our Medium Voltage Switchgear product is backed by comprehensive technical support and services designed to ensure optimal performance and reliability throughout its lifecycle. We offer expert installation guidance, routine maintenance programs, and prompt troubleshooting assistance to minimize downtime and enhance operational efficiency. Our team of skilled engineers provides detailed training sessions and technical documentation to empower your staff with the knowledge needed for safe and effective operation. Additionally, we supply original replacement parts and upgrade solutions to keep your switchgear up-to-date with the latest industry standards and technological advancements. Trust our dedicated support services to maximize the value and longevity of your medium voltage switchgear investment.

Packing and Shipping:

The Medium Voltage Switchgear is carefully packaged to ensure maximum protection during transportation. Each unit is securely wrapped with industrial-grade protective materials and placed in a custom-designed wooden crate to prevent damage from shocks, vibrations, and environmental factors.

All packaging materials comply with international shipping standards to guarantee safe delivery to the installation site. The crates are clearly labeled with handling instructions and product information for easy identification and careful handling.

For shipping, the Medium Voltage Switchgear is loaded onto pallets and secured using heavy-duty straps. Depending on the destination, transportation options include air freight, sea freight, or land transport, all coordinated to maintain the integrity of the product throughout the journey.

We also provide detailed shipping documentation, including packing lists, certificates of origin, and compliance certificates, to facilitate smooth customs clearance and timely delivery.

FAQ:

Q1: What is the brand and model number of the Medium Voltage Switchgear?

A1: The Medium Voltage Switchgear is branded as TIANAN and the model number is HXGT6-12.

Q2: Where is the Medium Voltage Switchgear manufactured?

A2: The Medium Voltage Switchgear is manufactured in China.

Q3: What certifications does the TIANAN HXGT6-12 Medium Voltage Switchgear have?

A3: The switchgear is certified under IEC and GB standards.

Q4: What is the minimum order quantity and packaging details for this product?

A4: The minimum order quantity is 1 set, and the product is packaged in a wooden case.

Q5: What are the delivery time and payment terms for ordering the Medium Voltage Switchgear?

A5: The delivery time is 30 days per set. Payment terms include FOB, EXW, CIF, and others.

Q6: What is the supply ability for the TIANAN HXGT6-12 switchgear?

A6: The supply ability is 500 sets per year.

Q7: How is the price of the switchgear determined?

A7: The price is to be confirmed based on order details and requirements.
