GB3906 and Other Standards High Voltage Disconnecting Switch 50/60 Hz Frequency Designed for High Voltage Applications

Product Description:

The Medium Voltage Switchgear product is a reliable and essential component for various electrical applications. Designed to meet the industry standards, this product offers exceptional performance and durability in demanding environments.

One of the key features of this Medium Voltage Switchgear is its rated short time withstand current. With options of 20, 25, 31.5, and 40 r.m.s, this product ensures efficient and safe operation during short circuit conditions, providing peace of mind to users.

Compliant with standards such as IEC298, GB3906, and other relevant regulations, this Medium Voltage Switchgear guarantees quality and reliability. The adherence to these standards reflects the commitment to delivering a product that meets the highest industry benchmarks.

The model KYN28A-14 is a standout in the Medium Voltage Switchgear category, known for its superior performance and robust construction. With a rated voltage of 24 KV, this model is suitable for a wide range of applications, offering versatility and flexibility to users.

In addition to its technical specifications, the Medium Voltage Switchgear is designed to operate efficiently within a wide ambient temperature range. With an operational range of -15℃ to +40℃, this product can withstand varying environmental conditions, making it suitable for diverse settings.

Overall, the Medium Voltage Switchgear product is a reliable and high-performance solution for applications requiring electronic dimmer switches, high voltage disconnect switches, and other critical components. With its advanced features, adherence to industry standards, and robust design, this product offers a dependable and efficient solution for medium voltage power distribution systems.

Features:

• Product Name: Medium Voltage Switchgear
• Rated current of branch busbar: 630, 1250, 1600, 2000, 2500, 3150 A
• Standards: IEC298, GB3906 And Other Standards
• Ambient temperature: -15℃~+40℃
• Model: KYN28A-14
• Degree of protection: Enclosure: LP4X

Technical Parameters:

Applications:

The product is suitable for use in power plants, industrial facilities, commercial buildings, and infrastructure projects. Its high voltage disconnecting switch feature ensures safe and efficient operation, making it ideal for controlling and protecting electrical circuits.

Whether it's managing power distribution in a manufacturing plant or ensuring grid stability in a utility substation, the KYN28A-24 switchgear provides the necessary functionality and performance. Its electronic dimmer switch capability allows for precise control of voltage levels, ensuring optimal power management.

The KYN28A-24 switchgear meets stringent industry standards such as IEC298 and GB3906, ensuring reliability and compliance with regulatory requirements. Its rated peak withstand current of 50, 63, 80, or 100 KA makes it suitable for handling high levels of electrical load.

In addition, the switchgear offers a high degree of protection with an enclosure rating of LP4X, making it suitable for use in harsh environments. Its model KYN28A-14 variant is specifically designed to withstand seismic intensity up to Grade 8, ensuring operational safety in earthquake-prone areas.

With a minimum order quantity of 1 set and a supply ability of 500 per year, the KYN28A-24 switchgear offers flexibility in procurement. Packaging details in wooden cases ensure safe transportation, while delivery within 30 days per set ensures timely deployment.

The product's payment terms include FOB, EXW, CIF, and others, providing convenience for customers worldwide. The price of the switchgear is to be confirmed, offering potential buyers the opportunity to negotiate based on their specific requirements.

Customization:

Product Customization Services for the Medium Voltage Switchgear:

Brand Name: TIANAN

Model Number: KYN28A-24

Place of Origin: CHINA

Certification: IEC&GB

Minimum Order Quantity: 1 SET

Price: To be confirmed

Packaging Details: WOODEN CASE

Delivery Time: 30 DAYS/SET

Payment Terms: FOB, EXW, CIF and so on

Supply Ability: 500 PER YEAR

Rated current of main busbar: 630, 1250, 1600, 2000, 2500, 3150 A

Rated peak withstand current(peak): 50, 63, 80, 100 KA

Degree of protection: Enclosure: LP4X

Ambient temperature: -15℃~+40℃

Altitude: ≤1000 M

Keywords: High Voltage Disconnect Switch, High Voltage Disconnecting Switch, Electronic Dimmer Switch

Support and Services:

Our Product Technical Support and Services for the Medium Voltage Switchgear include:

- Installation assistance and guidance to ensure proper set up of the switchgear system.

- On-site training for operators and maintenance personnel to enhance their understanding of the equipment.

- Remote troubleshooting and diagnostic support for quick resolution of any issues that may arise.

- Regular maintenance services to keep the switchgear in optimal working condition and prevent downtime.

- Upgrades and modifications to incorporate the latest technology and improve performance.

Packing and Shipping:

Product Packaging:

The Medium Voltage Switchgear is carefully packaged in sturdy cardboard boxes to ensure safe transportation. Each component is individually wrapped and cushioned to prevent any damage during shipping. The packaging is designed to withstand rough handling and protect the switchgear from moisture and dust.

Shipping:

We offer reliable and efficient shipping services for the Medium Voltage Switchgear product. Our team ensures that each order is processed quickly and accurately. We work with trusted carriers to deliver the switchgear to your doorstep in a timely manner. You can track your shipment online and rest assured that your product will arrive safely and on time.
